Description

LEWCO-W2215 Cameron Mud Pump

now offers a full line of premium expendables and service parts for all well-known makes and models of mud pumps that are currently in operation worldwide. These items include various styles of valves, pistons, liners, piston rods, and wear plates, as well as all fluid end seals and gaskets. We also offer a complete selection of fluid cylinder modules and major service components, such as crankshaft assemblies, gear sets,bearings, and connecting rods.
These parts combine the finest materials and manufacturing expertise, including the premium service and support that . has historically provided all our clients. The result is the best performing products available from any manufacturer. Whether you are running Brewster, Emsco, Ideco, Gardner-Denver, National, Oilwell, LEWCO, or Wirth pumps in your rig feet, VigorPetro is now a one-stop shop that can supply all the parts needed to keep these pumps running daily.

When you have questions pertaining to the parts and service offered in this catalog, we are ready to address your needs and welcome your call.

Part Inquiry for LEWCO-W2215 Cameron Mud Pump
Item Part Number Description Qty. Unit
1 ES331 LINER WASH PUMP PACKING 18 Ea
2 EG199 API ring gasket (BX-169SS) 27 Ea
3 EG197 API ring gasket (BX-152SS) 3 Ea
4 EG163 suction manifold gasket 15 Ea
5 B105281 suction dampener/desurger 3 Ea
6 108-0609 stroke counter 12 Ea
7 108-1054 heat exchanger-liner wash 3 Ea
8 108-1055 heat exchanger-lube oil 3 Ea
9 108-0764 low presure switch 3 Ea
10 ES452 low presure switch 3 Ea
11 108-1324 low presure switch 3 Ea
12 108-1225 v-belt 6 Ea
13 EG195 mud pressure gauge 3 Ea
14 EG170 crank case cover gasket 888 inch
15 A162209 inspection cover gasket 3 Ea
16 A164103 main bearing cover gasket 6 Ea
17 C164404 cross head cover gasket 6 Ea
18 A164185 inspection cover gasket (large) 3 Ea
19 108-1095 breather cap 3 Ea
20 A164191 stroke counter bracket gasket 3 Ea
21 B164202 eccentric bearing 9 Ea
22 EB119 main (spherical roller) bearing 6 Ea
23 B164206 main bearing shim set 6 Ea
24 A167244 eccentric bearing shims 6 Ea
25 EB120 pinion (cylinderical roller) bearing 6 Ea
26 ES194 oil seal 6 Ea
27 A164505 pinion bearing carrier gasket 6 Ea
28 B164402 wrist pin bearing 6 Ea
29 C164323 piston rod clamp 18 Ea
30 B164407 baffle disc 9 Ea
31 A164453 crosshead shim set 9 Ea
32 B164425 diaphragm plate gasket 9 Ea
33 ES211 stuffing box seal 36 Ea
34 A164415 stuffing box gasket 9 Ea
35 E0175 o-ring ( 2/343) 9 Ea
36 E0301 o-ring ( 2/442) 9 Ea
37 A164705 valve cover seal 18 Ea
38 A167708 valve guide bushing 36 Ea
39 A167702 wear plate seal 18 Ea
40 816406 wear plate seal 9 Ea
41 EV116 valve spring 36 Ea
42 EV190 valve seat 36 Ea
43 EV178 valve 36 Ea
44 EL238 liner (5″) 36 Ea
45 EL220 liner (5 1/2″) 36 Ea
46 EL221 liner (6″) 36 Ea
47 EL222 liner (6 1/2″) 36 Ea
48 EL223 liner (7″) 36 Ea
49 EL224 liner (7 1/2″) 36 Ea
50 EL240 liner (8″) 36 Ea
51 EP159 piston (5″) 36 Ea
52 EP160 piston (5 1/2″) 36 Ea
53 EP117 piston (6″) 36 Ea
54 EP118 piston (6 1/2″) 36 Ea
55 EP150 piston (7″) 36 Ea
56 EP151 piston (7 1/2″) 36 Ea
57 EP152 piston (8″) 36 Ea
58 EP165 piston (5″) 36 Ea
59 EP114 piston rubber(5 1/2″) 36 Ea
60 EP115 piston rubber (6″) 36 Ea
61 EP116 piston rubber (6 1/2″) 36 Ea
62 EP147 piston rubber (7″) 36 Ea
63 EP148 piston rubber(7 1/2″) 36 Ea
64 EP149 piston rubber (8″) 12 Ea
65 EG132 liner gasket (5″) 36 Ea
66 EG138 liner gasket (5 1/2″) 12 Ea
67 EG139 liner gasket(6″) 36 Ea
68 EG140 liner gasket(6 1/2″) 36 Ea
69 EG136 liner gasket(7″) 36 Ea
70 EG142 liner gasket (7 1/2″) 36 Ea
71 EG144 liner gasket (8″) 12 Ea
72 EP194 lube oil pump 3 Ea
73 108-0054 relief valve, 15 psi 3 Ea
74 108-1088 relief valve, 65 psi 3 Ea
75 108-0135 check valve 3 Ea
76 108-1257 flow switch 6 Ea
77 EG105 pressure gauge, 0-60 psi 6 Ea
78 EG145 pressure gauge 6 Ea
79 EV215 charging valve 6 Ea
80 ES175 stud 2.25 8UN 8.50 B7 36 Ea
81 EM132 heavy hex nut 8UN A194-2H 36 Ea
82 002-1666 hex bolt 1.000 8NC 2.00 G8 3 Ea
83 002-1544 lock washer 1.000″ 3 Ea
84 108-0620 stabilizer plate L-2010 3 Ea
85 108-0619 stabilizer L-20 3 Ea
86 EN137 havy hex nut 1.125 7NC A194-2H 24 Ea
87 EC181 bottom flange cap screw 24 Ea
88 108-0656 seal 429 BUNA 70 3 Ea
89 ES174 stud 1.125 7NC 6.5 B7 24 Ea
90 EO190 charging valve o-ring 6 Ea
91 108-0065 ring gasket BX-155S 3 Ea
92 B310066 charging valve hose assembly 3 Ea
93 108-0618 buna-N bladder ( standard) 6 Ea
94 108-1194 hydrogenated nitrile bladder(high temperature mud) 6 Ea
95 108-1195 Urthane bladder ( oil based mud) 6 Ea
