Description

DNV Certified 10ft Offshore Container

Offshore Container are mainly used on offshore oil platforms. They are much different with normal ISO container. Not only because strict safety requirements have to be met, but also because they are mainly transported by small ship and lifted/unloaded by crane. Herewith the main characteristic.

Design Standard

DNV2.7-1

DNV2.7-2
DNV2.7-3
EN12079
A60/H60 Standard

Container Structure

Main Post and Rail: Square Tube

Floor: Steel
Roof: Non Slip
Lifting: Sling via Padeye
Higher Grade Anticorrosive Paint

Testing

Main Structure Materials

Welding & Welder

2 / 4 Points Lifting
Quick Drop testing
Dimensions & Surface Treatment
BV / LR Certified 10ft DNV Offshore Container Price

This  DNV 2.7-1 container 10ft offshore container (DNV 2.7-1) has been modified and equipped with special equipment at the request of our customer.

* Exterior of the container was covered in high-quality paint coating.
* Recertification in accordance with DNV 2.7-1 guidelines.

Specification
Specification
DNV 2.7-1 container 10ft
External
2991 x 2438 x 2591 mm
Internal
2831 x 2353 x 2389 mm
Door opening
2340 x 2284 mm
MGW
10000 kgs
Tare weight
1950 kgs
Payload
8050 kgs
Capacity
15.9 kgs
Design temp.
-20
