The Model FL and FLS actuated gate valve has a slab gate design. A tight mechanical seal is obtained by the floating of the gate against the downstream seat.
Model FL and FLS bi-directional gate valve seals in either direction.
API 6A GATE VALVE DIMENSION AND WEIGHT DATA SHEET
Description
Model FL and FLS Bi-Directional Gate Valve
( DIMENSION AND WEIGHT INFORMATION FOR REFERENCE )
| Sre | Warking Preesur |
A Inch(mm) |
B Irch(mm) |
C Indh(mm) |
D Inch(mm) |
weleht bkg |
| 1-13/16 | 10.000 | 18.25(463.6) | 9.00(228.6) | 3.88 (98.6 | 5.75(146.1) | 180(82) |
| 15,000 | 18.00 (457.2) | 9.50 (241.3) | 3.88 (98.6) | 5.88 (149.4) | 230(104 | |
| 20,000 | 21.00 (533.4) | 11.38 (289.1) | 3.88 (98.6 | 7.88(200.2 | 450204 | |
| 2-1/16 | 2000 | 11.62 (295.1) | 6.09 (154.7) | 3.85 (97.8) | 5.28(134.1) | 74(34) |
| 3000 | 14.50 (368.3) | 7.00(177.8 | 3.85(97.8) | 5.50(139.7) | 127 (58) | |
| 5000 | 14.50 (368.3) | 7.00(177.8) | 3.85(978 | 5.50 (139.7) | 127(58 | |
| 10,000 | 20.50 (520.7) | 9.00 (228.6) | 3.88 (98.6) | 5.62.(142.7 | 197 (89) | |
| 15,000 | 19.00 (482.6) | 9.62 (244.3) | 3.88(98.6) | 5.88(149.4 | 244(111 | |
| 20,000 | 23.00 (584.2) | 11.75(298.5) | 4.55(115.6 | 7.50(190.5 | 661 (300 | |
| 2-9/16 | 2000 | 13.12 (333.2) | 7.00(177.8) | 4.66(118.5) | 6.00(152.4 | 109(50) |
| 3000 | 16.62 (422.1) | 7.88 (200.2) | 4.66(118.5) | 6.00(152.4 | 184(84) | |
| 5000 | 16.62 (422.1) | 7.88 (200.2) | 4.66(118.5) | 6.00(152.4 | 184(84) | |
| 10,000 | 22.25 (565.2 | 9.38(238.3 | 4.70 (119.3 | 6.75(171.5 | 301(136) | |
| 15,000 | 21.00 (533.4) | 11.25 (285.8) | 4.88(124.0) | 7.75(196.9 | 449 (204 | |
| 20,000 | 26.50(673.1) | 14.62 (371.3) | 6.50(165.1) | 10.00(254.0) | 988(448) | |
| 3-18 | 2000 | 14.12 (358.6) | 7.88(200.2) | 5.57 (141.5) | 7.12 (180.8 | 173(79) |
| 3000 | 17.12 (434.8) | 8.38 (212.9) | 5.57 (141.5) | 7.25(184.2) | 213(96) | |
| 5000 | 18.62 (472.9 | 9.12 (231.6) | 5.57 (141.5) | 7.25(184.2) | 260(118 | |
| 3-1/16 | 10,000 | 24.38(619.3) | 10.12 (257.0) | 5.60 (142.3 | 8.12 (206.2 | 408(185 |
| 15,000 | 23.50 (596.9) | 13.75(349.3) | 6.13(155.8) | 9.75(247.7) | 726 (329 | |
| 4-18 | 2000 | 17.12 (434.8) | 9.62 (244.3) | 7.20(182.8) | 9.00 (228.6 | 292(132 |
| 3000 | 20.12 (511.0) | 10.38(263.7) | 7.20(182.8) | 8.75 (222.3 | 351 (159) | |
| 5000 | 21.62 (549.1) | 10.75 (273.1) | 7.20(182.8) | 9.88(251.0) | 468 (212 | |
| 4-1/16 | 10,000 | 26.12 (663.4) | 12.75 (323.9) | 7.23 (183.6) | 10.25(260.4) | 713 (324) |
| 15,000 | 29.00736.6 | 14.50(368.3) | 7.70(195.5) | 11.62(295.1) | 1136(515) | |
| 5-18 | 2000 | 22.12 (561.8) | 11.00 (279.4) | 8.85(224.8) | 12.62(320.5) | 831377 |
| 3000 | 24.00(609.6 | 13.00 (330.2) | 8.85(224.8) | 12.75(323.9) | 852(387) | |
| 5000 | 28.62 (726.9) | 11.50 (292.1) | 8.85 (224.8) | 12.62(320.5) | 984(446 | |
| 10,000 | 29.00(736.6) | 14.50 (368.3) | 9.44 (239.7) | 13.25(336.6) | 1013 (459) | |
| 6-18 | 5000 | 29.00(736.6 | 14.12 (358.6) | 10.32 (262.1) | 1288(327.2) | 1021(463) |
| 6-38 | 2000 | 22.12 (561.8) | 12.38 (314.5) | 10.32 (262.1) | 12.88(327.2) | 785 (356 |
| 3000 | 24.12 (612.6 | 12.62 (320.5) | 10.32 (262.1) | 12.88(327.2 | 864(392) | |
| 5000 | 29.00 (736.6) | 14.12 (358.6) | 10.32 (262.1) | 12.88(327.2) | 997 (452 |
