- Kit includes:
- Replacement Plug
- Insert Set
- Seal Kit
Halliburton Type Plug Valve Repair Kit
Description
Halliburton Type Plug Valve Repair Kit
These repair kits are replaceable and interchangeable for Weir SPM™, FMC™ 1” 2” and 3” DR plug Valve, which is including plug, seal segment, side segment, elastomer seals, and grease fittings.
Size:
1” Plug Valve Low Torque (1 x 1) Male x Female FIG1502
1” Plug Valve Low Torque (1 x 2) Male x Female FIG1502
2” Plug Valve Low Torque (2 x 2) Male x Female FIG1502
3” Plug Valve Low Torque (3 x 3) Male x Female FIG1502
Cold working pressures: 42Mpa (6000Psi), 70Mpa (10000Psi), 105Mpa (15000Psi).
Connection type: hammer union (Fig.602, Fig.1002, Fig.1502 MXM, MXF, and FXF), LP female thread and LP external thread and the plug valve with bottom base can be designed upon the client’s request.
| No. | Name | Qty | No. | Name | Qty | |
|---|---|---|---|---|---|---|
| 1 | Valve body | 1 | 12 | Square sealing ring | 2 | |
| 2 | Sealing washer | 1 | 13 | Sealing arcing shim | 2 | |
| 3 | Spring rand | 1 | 14 | Plug cock | 1 | |
| 4 | Wing union | 1 | 15 | Valve deck sealing ring | 1 | |
| 5 | Rand | 3 | 16 | Support band of valve deck sealing ring | 1 | |
| 6 | Retaining spring | 1 | 17 | Elastic cylindrical pin | 1 | |
| 7 | Retaining pin | 2 | 18 | Valve deck | 1 | |
| 8 | Locating pin | 2 | 19 | Plug cock cap | 1 | |
| 9 | O-shaped sealing ring | 2 | 20 | Locknut | 1 | |
| 10 | Sealing ring support band | 2 | 21 | Grease fitting | 1 | |
| 11 | Side arcing shim | 2 |
