Description
Cast, Ductile iron Strainer
Short Description
Model No.: LD-028-YS3 Hits: 3002
Cast, Ductile iron Strainer Manufacturer CAMTOP Supplies Cast Iron Strainers, Ductile Iron Strainers, Suitable for Water, steam, and oil Medium.
Key Specifications / Features
Cast Iron Strainer, Ductile Iron Strainers
Application:Water, steam, and oil as suitable medium
Strainer Size: 1/2 to 12 inches
Nominal pressure: PN1.0/1.6mPa
Dimension: ANSI B16.1, DIN3202-F1, and BS2080
Flange drilled is according to ANSI B16.1, ANSI B16.5, DIN 2501, and BS4504
Test standard: API 598
Strainer Body and bonnet: cast-iron and ductile-iron
Disc: cast-iron, ductile-iron, and rubber
Mesh Screen: stainless steel
Bolt and nut: carbon steel with zinc-plated
Standard: ANSI, DIN3202-F1, and BS2080
