BTC8200/BTC8200A Explosion-proof Floodlight

Application places: It is used for the fixing lighting under emergencies, for new devices, oil tanks, pipelines, roads and oil depots and gas stations of oil sales company. Structural features: 1. The explosion-proof lamp has the highest explosion-proof level and it can be used in flammable and explosive places safely and reliably; 2. High-intensity gas discharge lamp is used as the light source and it has high lighting effects and long service life. The lamp has an average service life of over 10000 hours. 3. Imported light alloy material is adopted, thus the lamp can resist strong collision and shock. 4. Optimized structural design and sealing process are adopted to ensure the lamp has good waterproof and dust-proof performance and can work reliably in harsh environment. 5. The lamp has small volume, light weight, simple and easy installation and operation and it can be installed in the form of base, wall mounting and ceiling.

Technical Parameters:

1. Explosion-proof mark: Ex ⅡC T4/T6 2. Rated voltage: 220VAC 50Hz 3. Shell protection: IP65 4. Insulation grade: I 5. Corrosion-proof level: WF2; 6. Cable: φ8~φ10mm (lamp), φ8~φ14mm (ballast box) 7. Space-depth ratio: 0.4 (BTC8200),0.8(BTC8200A)
